Vertical drilling machine STH S-Drill H30
In Stock
Product code: S-Drill H30
204 900 ₴
Get consultation
Extended warranty
An additional 6 months warranty from our campaign
Extended warranty - we are confident in the quality of the products we supply, so we offer our customers an additional 6 months warranty from our company to the standard warranty period from the manufacturer. For the entire range, which you can find on our website.
Proven manufacturer
We were on the production floor and checked it out
Only tested equipment - we only supply equipment from manufacturers whose factories we have visited and made sure that their quality is worth your attention.
Professional service
We guarantee quality and prompt service
Professional service - our team provides quality service at all stages of your equipment's life: installation and setup, warranty and post-warranty service and repair.
Characteristics
Vertical drilling machine STH S-Drill H30
Machine type
Vertical drilling machine
Accuracy rating
Normal
Max. diameter of drilling in steel, mm
30
Max. diameter of thread cutting in steel, mm
М20
Spindle taper
МТ3
Min. spindle rotation speed, rev/min
65
Max. spindle rotation speed, rev/min
2600
Number of spindle rotation speeds
12
Spindle power, kW
1.1
Table width, mm
440
Table length, mm
500
Distance from the axis of the spindle to the guide, mm
320
Rassotoyanye from the table to the end of the spindle, mm
550
Column diameter, mm
120
Spindle stroke, mm
135
Number of pitches
3
Min. working feed, mm/min
0,1
Max. working feed, mm/min
0.3
Power supply, V
380
Dimensions (L), mm
1080
Dimensions (W), mm
620
Dimensions (H), mm
2050
Net weight, kg
500
Description
Vertical drilling machine STH S-Drill H30
Vertical drilling machine STH S-Drill H30
